| Adhesive |
BWP grade synthetic resin |
| Gap, Split, Overlap, Warp |
Negligible |
| Moisture Content(%) |
5 - 12 |
| Glue Shear Strength (GSS)(N) |
| Average : >1350 |
| Individual: >1100 |
|
| GSS Wet Test (N) |
| Average : >1000 |
| Individual : >800 |
|
| GSS Mycological Test (N) |
| Average : >1000 |
| Individual : >800 |
|
| Preservative Treatment |
| Two Tier Treatment: |
| 1. Glue Line protection (GLP) |
| 2. Finished panels are treated with ACC (Acid Copper chrome Compound) |
|
| Specific Gravity |
Approx. 0.75 |
| Water Absorption(%) |
< 5 |
| Warranty |
Cost of furniture or 2 times the ply cost, whichever is lower |
| Pre-pressing |
Flat panel/balanced surface |
| Face Thickness |
Thicker face |
| Veneer to Veneer Ratio |
As per standards |
| Static Bending Strength Dry(N/mm2) |
| Modulus of rupture (MOR) |
| Along the grain | Across the grain: |
| Average : >40 | Average : >20 |
| Min. Individual : >36 | Min. Individual : >18 |
|
|
| Modulus of elasticity (MOE) |
| Along the grain | Across the grain |
| Average : >5000 | Average : >2500 |
| Min. Individual : >4500 | Min. Individual : >2200 |
|
